RTM-12A
Ren Thang Machine
The RTM-12A (officially updated in the 20260825 catalog, superseding RTM-12n) is a fully automatic SMD reel component counter featuring quick-lock reel derailment clamps and a graphic backlit LCD. With a ±99,999 count capacity, preset motor braking, and a portable 6 kg frame, it eliminates manual counting errors.
Processing & Feature Tags
REL
Reels
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 全自動高速計數，容量 -99,999 ~ 99,999
Power / Air Supply AC110V(60Hz) / AC220V(50/60Hz) (30W)
Standard Tolerance 高精確光纖感應，零誤差計數
Dimensions (L×W×H) 289(L) × 419(W) × 177(H) mm
Net Weight 6 kg
Catalog Page & Status
P.12 (Catalog_0012) • 在產 (Active)
【Key Machine Features & Advantages】
- Fully automatic SMD chip counter tailored for fast and precise counting, kitting, and inventory stocktaking of taped SMD components.
- Quick-lock reel derailment protection device keeps reels securely aligned; effortless adjustment by simple knob tightening/loosening.
- Graphic LCD display panel provides clear visual guidance, intuitive parameter setting, and instant readout of batch quantities.
- Wide counting range from -99,999 to +99,999 with preset target batch count and automatic motor braking.
- Compact, lightweight design (only 6 kg; 289 × 419 × 177 mm) with low power consumption of 30W for easy mobility between production lines.
- Officially updated to model designation RTM-12A according to the 20260825 catalog revision (superseding older RTM-12n markings).
- Eliminates manual counting errors, accelerating inventory turnover and ensuring flawless BOM kit preparation.
【Revision Notes】 依 20260825 最新型錄修訂，舊款 RTM-12n 正式統一命名為 RTM-12A。
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic RTM-12A
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| APPLY_PKG | Applicable Packages | SMD 捲帶 (Tape & Reel SMD Only) | Fully automatic high-speed inventory |
| COUNT_RANGE | Count Capacity | -99,999 ~ +99,999 | Positive and reciprocal accurate inventory to prevent fools |
| POWER_W | Power Consumption | 30 W | AC110V/220V energy-saving and low-power consumption design |
| DISPLAY | Display Panel | 繪圖型 LCD 液晶顯示幕 (Graphic LCD) | Clear and easy-to-read setting parameters and data |
| REEL_PROTECT | Reel Protection Device | 快速旋扭式防脫料帶裝置 | Easy tightening/loosening operation without damaging the material belt |
| PRESET_STOP | Preset Batch Control | 支援預設目標數量與自動停機 | Quick delivery to prevent shortage or excess |
