IC Self-Regulating Temperature Solder Pot - Round (KC Series)
圓形有鉛/無鉛焊錫爐
The KCXXXX series encompasses industrial round solder pots (KC-35 through KC-100) featuring titanium alloy or high-grade stainless steel crucibles. Delivering rapid, uniform heating and lead-free corrosion resistance, precision temperature controllers ensure stable dip-soldering for component leads and wire enameling.
Processing & Feature Tags
電子零件
漆包線
電線接頭
拔IC零件
熔蠟
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 輕便桌上型即時浸焊作業
Power / Air Supply 110V / 220V 50/60Hz (350W ~ 550W)
Standard Tolerance 控溫 0 ~ 500°C (指針) / 0 ~ 475°C (數位)
Dimensions (L×W×H) 錫杯 ø60×40mm, ø80×40mm, ø100×40mm
Net Weight 2.2 ~ 4.7 kg (熔錫量 1.2 ~ 2.5 kg)
Catalog Page & Status
P.24 (Catalog_0024) / 功程目錄 • 量產中
【Key Machine Features & Advantages】
- Analog Dial & Digital PV Display: Offers both cost-effective analog dial models (KC-60H/80H/100H) and high-accuracy digital PV LED display models (KC-60PV/80PV/100PV).
- Comprehensive Leaded & Lead-Free Lineup: Full range available in standard leaded versions and corrosion-resistant lead-free pure titanium cup editions.
- Compact Benchtop High Mobility: Lightweight benchtop design (2.2 ~ 4.7 kg) takes minimal workbench space and enables immediate plug-and-play operation.
- IC Closed-Loop Constant Temperature: High-sensitivity IC thermal regulation spanning 0~500°C (analog) / 0~475°C (digital), ensuring swift heat-up and stable temperature recovery.
- Wide Anti-Spill Dross Scraper Lip: Ergonomic beveled overflow collar allows effortless solder dross skimming without splashing, maintaining a clean workstation.
- Versatile Tinning & Complete Spares: Ideal for component lead tinning, wire terminal stripping/tinning, small PCB repair, IC de-soldering, and wax melting; full inventory of 4/6/8/10cm cups and heaters.
【Revision Notes】 依 2026.09.11 最新報價單核實更新：含 KC-60H/80H/100H 及 KC-60PV/80PV/100PV 有鉛無鉛全系列
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic KCXXXX
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| MODELS_DIAL | Analog IC Solder Pot Models | KC-60H (ø60×40mm), KC-80H (ø80×40mm), KC-100H (ø100×40mm) | Power 350W / 450W / 550W, weight 2.2kg / 3.1kg / 4.7kg, knob stepless temperature adjustment |
| MODELS_DIGI | Digital IC Solder Pot Models | KC-60PV (ø60×40mm), KC-80PV (ø80×40mm), KC-100PV (ø100×40mm) | LED digital real-time temperature display (PV), high-precision IC constant temperature closed-loop control |
| LEAD_FREE_VER | Lead-Free Models Spec | KC-60H/80H/100H (無鉛) 及 KC-60PV/80PV/100PV (無鉛) | Using extra-thick corrosion-resistant pure titanium/corrosion-resistant alloy tin cup, specially designed to deal with lead-free high melting point solder erosion |
| CAPACITY_WEIGHT | Solder Capacity Weight | KC-60: 1.2 kg ; KC-80: 2.0 kg ; KC-100: 2.5 kg | Meets the needs of all kinds of micro- to medium-sized parts for lead tin immersion, wire harness tin immersion and repair welding |
| TEMP_RANGE | Temperature Range | 0°C ~ 500°C (指針) / 0°C ~ 475°C (數位 PV) | IC automatic constant temperature, rapid temperature rise and recovery, high safety and protection |
| SLAG_RING | Solder Dross Overflow Lip | 標準配備廣角斜緣撥渣承接環 | External flip-out design, easy scraping of tin oxide slag to prevent spillage, keeping the work surface clean |
| SPARE_PARTS | Consumables & Spare Parts | 4/6/8/10cm 有鉛/無鉛錫杯、電熱圈、IC機座、數位IC座、感溫線、繼電器 | Complete range of original factory specification consumables, easy replacement and low maintenance costs |
