KA-22
Ren Thang Machine
The KA-22 is a flagship automatic dual-spindle PCB lead cutter featuring integrated motorized copper brush cleaning for extra-wide boards up to 420 mm wide. Its rough-cut and finish-cut dual blades balance mechanical load, while the rotating brush actively sweeps away trimmed lead debris and solder dross.
Processing & Feature Tags
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 速度 0 ~ 3 M/min 可調 (約 800 ~ 1,500 片/小時)
Power / Air Supply 380V, Single phase (雙主軸 3/4 HP, 4,500 RPM + 銅刷 1/5 HP, 600 RPM)
Standard Tolerance 最低腳高 1.0mm (高密度基板精密剪腳)
Dimensions (L×W×H) 2700(L) × 1200(W) × 1100(H) mm
Net Weight 350 kg
Catalog Page & Status
P.14 (Catalog_0014) • 在產 (Active)
【Key Machine Features & Advantages】
- Flagship automatic dual-spindle PCB lead cutter with integrated copper brush, built for extra-wide boards and high-density PCBA lines.
- Wide processing range: handles PCB widths from 10 to 420 mm (unlimited length), ideal for large server boards and power supplies.
- Dual-blade design (rough cut + finish cut with 3/4 HP, 4,500 RPM spindle) balances cutting load and significantly extends blade life.
- Integrated motorized copper brush (600 RPM / 1/5 HP) actively sweeps away solder dross and trimmed lead residuals from the board underside.
- Stepless conveyor feed rate from 0 to 3 m/min with height-adjustable entry/exit tracks for seamless docking to any wave soldering brand.
- Integrated hold-down plates and support pins prevent board sagging or thermal warping during high-speed cutting.
- Heavy industrial chassis (350 kg; 2700 × 1200 × 1100 mm) dampens mechanical resonance for quiet, ultra-stable 24/7 continuous operation.
- Recommended with NK-200 / NK-250 micro-grain tungsten carbide circular blades (optional accessory).
【Revision Notes】 銜接軌道前後高低可調，適用不同廠牌焊錫爐；鎢鋼刀NK-200/NK-250為選購品。
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic KA-22
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| PCB_WIDTH | Applicable PCB Width | 10 ~ 420 mm (長度不限) | Supports ultra-large substrates and motherboards/power boards |
| THICK_RANGE | Rail Thickness Range | 0.8 ~ 2.5 mm | Chain conveyor claw type stable clamping |
| SPINDLE_DUAL | Twin Spindle Configuration | 粗剪刀 + 精剪刀 (3/4 HP, 4,500 RPM) | Dual-pass process shares the cutting load to extend the life of the cutter |
| COPPER_BRUSH | Motorized Brass/Copper Brush | 600 RPM / 1/5 HP 專用銅毛刷 | High-speed brushing to remove sticky wire leads and residual tin slag on the bottom of the board |
| FEED_SPEED | Conveyor Feeding Speed | 0 ~ 3 M / 分鐘 (連續速度可調) | Adjustable front and rear height of the track to flexibly dock solder furnaces of various brands |
| WARP_PROOF | Hold-Down & Support Pins | 附頂針及壓板防變形裝置 | Ensure the flatness of ultra-wide and thin PC boards Anti-wound board |
